Settings
| Setting | Description |
|---|---|
| X | Left coordinate of the preview element |
| Y | Top coordinate of the preview element |
| Width | Width of the preview element |
| Height | Height of the preview element |
| Rotation | Apply a rotation to the preview element |
| Scene | Select from which 3D Scene to recall a view Multiple 3D Scenes can be used simultaneously in the same page |
| View type | Select whether to recall a Preset, a Camera view or a Projector view |
| Preset | Select which Preset, Camera or Projector view to display Depends on the choice of View type |
| Draw scene | Toggle to enable/disable drawing the 3D objects present in the scene Note they will be drawn as black instead |
| Draw cameras | Toggle to enable/disable drawing the cameras present in the scene |
| Draw projectors | Select in the dropdown which projectors to draw in the Preview. Use the Select all and Unselect all buttons for quickly adding/removing all projectors |
| Draw projector infos | Toggle to enable/disable the drawing of projector infos in the preview |
| Draw projector beams | Toggle to enable/disable the drawing of projector beams in the preview. Note: Beams will only be drawn if the Show Beam option is enabled in the 3D Scene. |
| Draw projections | Toggle to enable/disable the drawing of projector study modes in the preview. The legend size of the study modes can be modified here. |
| Draw dimensions | Toggle to enable/disable the drawing of dimensions in the preview |
| Draw annotations | Toggle to enable/disable the drawing of annotations in the preview |
| Draw lights | Toggle to enable/disable the drawing of lights in the preview |
| Draw skeletons | Toggle to enable/disable the drawing of skeletons in the preview |
| Lock position | Toggle to lock the position and dimensions of the element |
