This device allows you to receive or send MIDI event and receive MTC MIDI Timecode.
You need to add a USB external MIDI interface to use this device.
Settings:
Name: User-friendly name
Input Enable: Enable or disable input
Input Port: Choose Input port from list
Output Enable: Enable or disable output
Output Port: Choose output port from list
Timecode Type: Choose from list
Task action:
Note On/Off: Channel value (range 1-16), Note (range 1-128), Velocity (1-128)
Control Change: Channel value (range 1-16), Control (range 1-128), Value (1-128)
Program change: Channel value (range 1-16), Program(range 1-128)
MMC Stop/Play: Device Id value (range 0:127)
MMC Deferred Play: Device Id value (range 0:127)
MMC Fast Forward: Device Id value (range 0:127)
MMC Rewind: Device Id value (range 0:127)
MMC Punch In: Device Id value (range 0:127)
MMC Punch Out: Device Id value (range 0:127)
MMC Pause: Device Id value (range 0:127)
MMC Goto: Device Id value (range 0:127), Timecode (hh:mm:ss:ff)
Task trigger:
Action:
Note On: Channel value (range 1-16), Note (range 1-128), Velocity (1-128)
Note On No Velocity: Channel value (range 1-16), Note (range 1-128)
Note Off: Channel value (range 1-16), Note (range 1-128), Velocity (1-128)
Control Change: Channel value (range 1-16), Control (range 1-128), Value (1-128)
Program change: Channel value (range 1-16), Program(range 1-128)
Digimap trigger:
Action:
Note On/Off: Channel value (range 1-16), Note (range 1-128)
Control change: Channel value (range 1-16), Control (range 1-128)
Program Change: Channel value (range 1-16)
User interface:
N/A
Device information:
See here more information about MIDI protocol.
