Select this device to control your Optoma video projectors.
Settings
| Property | Default | Description |
|---|---|---|
| Name | Optoma | User-friendly name. |
| IP | [empty] | Enter the IP address of your device. Your device and Remote should be on the same subnet. |
| Port | 23 | TCP/IP port used by the device. |
Task action
| Action | Description |
|---|---|
| Power On/Off | Toggle the power on the projector |
| Shutter On/Off | Toggle the shutter |
| Channel | Select the input for the video signal |
| Freeze On/Off | Toggle the freeze on the input signal |
| Internal Test pattern | Select an internal test pattern to output |
| Focus increase/decrease | Adjust the focus value more or less |
| Zoom increase/decrease | Adjust the zoom value more or less |
| Horizontal shift | Adjust the horizontal shift value more or less |
| Vertical Shift | Adjust the vertical shift value more or less |
| Aspect Ratio | Set the aspect ratio on the output |
Task trigger
This device has no actions that can trigger a Task.
Digimap trigger
This device has no actions that can trigger a Digimap.
User interface
When drag & dropped into a UI Panel the following commands are available:
Manual controls of the Optoma device in the Editor panel.Device information
Check Optoma’s website for more information on their video projectors.
