Description
Modulo Bridge enables communication with USB devices that lack Ethernet support.
For more information, you can read the product sheet.
This device works in conjunction with some scanners and cameras.
For more information on the setups you can read the application notes :
- Projection with photobooth integration
- Interactive setup with live artwork scanning
Settings
| Property | Default | Description |
|---|---|---|
| Name | ModuloBridge | User-friendly name. |
| Enable | ON | Activate to enable the device. |
| Run at startup | ON | Activate to enable the device at Kinetic startup. |
| IP | [empty] | Enter the IP address of your device. Your device and Kinetic Designer should be on the same subnet. |
| MAC | [empty] | MAC address of the network interface on remote device (Only required to use Wake On Lan function) |
Task action
| Action | Description |
|---|---|
| Enable | Enable the device |
| Disable | Disable the device |
| Reboot Server | Reboot the remote device |
| Power Off | Power Off the device |
| Wake Up On Lan | Power On the remote device through its network interface (Requires MAC address to be setup in the device properties) |
Task trigger
This device has no actions that can trigger a Task.
Digimap trigger
N/A
Graph
This device has no actions that can be used in a Graph.
User interface
This device has no actions that can be launched from the UI designer.
